FIX’N GO PATCH®

HOT-PRESS METHOD SPLICES

Z-splice – Meets the most stringent requirements for uniformity of thickness. Very flexible splice, especially well suited for knife edge belt types. Standard splice angle is 90° (60° is possible).

Stepped Z-splice – Similar properties as the Z-splice. Also suitable for harsh operating conditions. Possible on various 2 and 3-ply belt types.

Wedge splice – Splice type used for solid-woven and NOVO types. Splice angle is 90°.

Overlap splice – Especially well suited for 2 and 3-ply belt types with duroplastic surface materials. Splice angles are 90° or 80°.

MECHANICAL FASTENERS

Hook fasteners (HS) – Stainless, antimagnetic, sheathed connecting rod. Can also be embedded or heated into belt surface material.

Plastic fasteners (KS) – White polyester, FDA, heated into belt surface material.

Clamp fasteners (CS) – Stainless or standard, sheathed connecting rod.
